Composite rolls
●Special cemented carbide grades are used for hot rolling rods and ribbed steel bars
●With hydraulic nuts locking devices and in-feed of oil with pressure of 100-200 Mpa,the hydraulic
nuts create an axial pretighening force of 500-1500KN and fasten the cemented carbide roll rings to the mother shafts.The devices are practical in use and reliable and they can insure higher performaces of composite cemented carbide roll rings under the protection of a proper prestress.
●Various cemented carbide roll rings are available with diameter ofφ300-400mm and thickness of30- 159mm for sizing mills.
●Various composite cemented carbide roll rings for hot rolling ribbed steel bar and rods.
Services are provided such as composite rolls design,groove machining and thread processing.
●Various compatible tools can be provided for machining composite cemented carbide roll rings.
Description
The rolling quantily of composite cemented carbide rolls
|
Specification (mm)
|
The rolling quantityof singlegroove(ton) |
||
|
Stands of finished products K1 |
The front stands of finished products K2 |
Slitter K3、K4 |
|
|
φ10 |
>600 |
>1500 |
>3000 |
|
φ12 |
>800 |
>2000 |
>4000 |
|
φ14 |
>1400 |
>3000 |
>6000 |
|
φ16 |
>1600 |
>3500 |
>7000 |
|
φ18 |
>1800 |
>4000 |
>8000 |
|
φ20 |
>2000 |
>5000 |
|
|
φ22 |
>2200 |
>6000 |
|
|
φ25 |
>2500 |
>8000 |
|
Cemented carbide composite rolls specifications
|
Outer diameter range(mm) |
Width range(mm) |
Rolling size range(mm) |
|
285-480 |
50-140 |
5-28 |
Rolling process for hot rolling rods and rebar
|
Name |
Single rolling |
2clit rolling |
3clit rolling |
Recommend materials |
|
K1 Group |
|
|
|
Cemented carbide |
|
K2 Group |
|
|
|
Cemented carbide |
|
K4 Group |
|
|
 |
Cemented carbide |
We can design and manufacture single-line rolling,two-slit rolling,three-slit rolling and combined hard alloy rolls according to customer production line and rolling process.The products include wire,bar and rebar.
The high output of the cemented carbide composite roll can effectively reduce the times of roll changes and increase the unit output.The products are produced have the characteristics of good quality on the surface,small deformation,high negative tolerance rate and finished product rate.
